Two totalizers: 1 x 8 digit fixed, 1 x 4 digit resettable.
20 - 120L/min flow rate.
1" BSPF inlet & outlet.
Working pressure 0.1 - 3.5bar.
Specifications:
Fluid or Medium Type: Diesel
Flow Range: 20-120L/min
Pressure Range: 0-3.5bar / 0-50psi
Inlet Connection: 1" BSPF
Outlet Type: 1" BSPF Port
Meter Accuracy: ±1%
Duty: Standard Duty
